SKU# 47CPT44Z

SIMPSON CPT44Z 4X4 CONCEALED POST BASE FOR WRAPPING POSTS

CPT44Z
2 Available

Product Overview

The CPTZ concealed post base provides a clean, concealed look while providing a 1" standoff height above concrete. The 1" standoff reduces the potential for decay at the post end and satisfies code requirements for posts that are exposed to weather, water splash or in basements. It is part of a system of concealed connectors that includes the CBTZ and CJT.

Key Features

  • The CPTZ is tested and load rated for uplift, download and lateral load.
  • Simpson Strong-Tie saves installers time by providing all the necessary components to make the post connection in one box (anchors not included).
  • There are two anchorage solutions available. See tables for information.
  • Solutions have been calculated per ACI 318 to determine their allowable load in different concrete configurations.

Product Specifications

Base Material

12 GA

Brand

Simpson Strong-Tie

Knife Plate

10 GA

Length

3-1/2 in

Model #

CPT44Z

Post Size

4 x 4

Width

3-1/2 in
