SKU# 47110000
SIMPSON LTB20 METAL BRIDGING 16"OC FOR 2X8/2X10 (200 PCS/BX)
UPC Code: 044315478901 Manufacturer Part #: LTB20 METAL BRIDGINGOut of Stock at Arlington Coal & Lumber
Store: Arlington Coal & Lumber
Pickup available at
Product Overview
The LTB provides bracing between floor joists as a critical contribution to the structural strength of a floor. Installed in pairs this light tension-type bridging keeps joists in place and prevents them from rotating while distributing loads over more than one joist. The LTB features a staggered nail pattern to accommodate 2x8 and 2x10 joists and is designed for maximum nailing flexibility with the option to use as few as two nail holes on each end and as many as six.
Key Features
- Galvanized for corrosion resistance
- Keeps floor system continuity and prevents joist rotation
- Installation flexibility with six nail holes on each end and a staggered nail pattern
Product Specifications
| Brand |
Simpson Strong-Tie |
| Gauge |
22 GA |
| Length |
19-1/2 in |
| Material |
Zinc Galvanized |
| Model # |
LTB20 |
| Width |
3/4 in |
